3/8-16 H5 Powertap ANSI Plug Oxide Cobalt

Series Number: 4402_EDP/Part Number: 9044025095250_Order Code: 509.525_Package Quantity: 1_EAN Number: 4049844133884_Item Dimensions (mm): 9.525 X 74.700_Item Weight: 0.0794_Package Weight: 0_Coating Steam Oxide_Class of Fit 2B_Coolant Without_Cutting Direction Right Hand_Form 3.5-5 Form B_Material HSS-E_Thread Type UNC_Type Powertap_Shank Cylindrical_Standard ANSI_EDP # : 9044025095250_Size d1 - P (inch): 3/8-16_H Limits : H5_Tap Drill Range dk (inch): 0.3161_Number of Flutes : 3_Shank Ø d2 (inch): 0.381_Square SW (inch): 0.286_OAL l1 in: 2.941_Neck Length l3 (inch): 1.456_Code No. : 509.525_EDP/Part Number: 9044025095250_Series-Code: 4402-509.525_EDP # : 9044025095250_Size d1 - P (inch): 3/8-16_H Limits : H5_Tap Drill Range dk (inch): 0.3161_Number of Flutes : 3_Shank Ø d2 (inch): 0.381_Square SW (inch): 0.286_OAL l1 in: 2.941_Neck Length l3 (inch): 1.456_Code No. : 509.525_EDP/Part Number: 9039130095250_Series-Code: 3913-9.525_EDP # : 9039130095250_Size d1 - P (inch): 3/8-16_H Limits : H5/H6_Tap Drill Range dk (inch): 0.307 - 0.321_Number of Flutes : 3_Shank Ø d2 (inch): 0.381_Square SW (inch): 0.286_OAL l1 in: 2.941_Neck Length l3 (inch): 1.456_Code No. : 9.525_Powertap Taps_Wh
